2 CONSOLESWITCH SCS232 USER’S MANUAL

CHAPTER 2: INTRODUCTION 3 CHAPTER 2: INTRODUCTION CONSOLESWITCH SCS232 FEATURES • Dual user, simultaneous matrixed access to 32 serial devices •

4 CONSOLESWITCH SCS232 USER’S MANUAL PRODUCT PHOTOS Figure 1. ConsoleSwitch SCS232 Front Figure 2. ConsoleSwitch SCS232 Back RELATED

CHAPTER 3: INTRODUCTION REQUIREMENTS 5 CHAPTER 3: CABLING REQUIREMENTS CONSOLESWITCH CABLING: SERIAL OVER UTP NOTE: The following information applie

6 CONSOLESWITCH SCS232 USER’S MANUAL PARAGON CABLING: KVM OVER UTP NOTE: The following information addresses the stricter cabling requirements of Rar

CHAPTER 4: INSTALLATION 7 CHAPTER 4: INSTALLATION CONSOLESWITCH STANDALONE INSTALLATION NOTE: The following information applies to configurations

8 CONSOLESWITCH SCS232 USER’S MANUAL CONNECTING USER CONSOLES 1. In your ConsoleSwitch shipment (see Chapter 2: Introduction - Package Contents), you

CHAPTER 4: INSTALLATION 9 POWER ON 1. With your user consoles and devices attached, connect the supplied AC power cord to ConsoleSwitch, and switch

10 CONSOLESWITCH SCS232 USER’S MANUAL This section only applies if you wish to operate ConsoleSwitch with a user console (dumb terminal or terminal em

CHAPTER 4: INSTALLATION 11 PREPARE DEVICES Devices to be controlled by Paragon through ConsoleSwitch must be set at the following communications set

This page intentionally left blank

12 CONSOLESWITCH SCS232 USER’S MANUAL CONNECTING CONSOLESWITCH TO PARAGON All cabling performed in the following steps must conform to the requirement

CHAPTER 4: INSTALLATION 13 2. When the update is complete, login as “admin” (default password is “raritan”). Channel numbers corresponding to Parag

14 CONSOLESWITCH SCS232 USER’S MANUAL

CHAPTER 5: OPERATING CONSOLESWITCH 15 CHAPTER 5: OPERATING CONSOLESWITCH PARAGON OPERATION: VIEWING STORED DATA When using ConsoleSwitch in tandem

16 CONSOLESWITCH SCS232 USER’S MANUAL ACCESSING THE MAIN MENU • At any time while in HotKey mode, you may invoke the main menu by pressing H ↵. •

CHAPTER 5: OPERATING CONSOLESWITCH 17 SELECTING A CHANNEL By Channel Number. To select a channel by number from the main menu, simply enter the keyst

18 CONSOLESWITCH SCS232 USER’S MANUAL D — Display Scan List To see a list of all channels on your scan list, press D ↵. This screen is identical to t

CHAPTER 5: OPERATING CONSOLESWITCH 19 F# — Forward # Lines Moves the display cursor a user-determined number of lines forward to a new screen starti

20 CONSOLESWITCH SCS232 USER’S MANUAL

APPENDICES 21 APPENDICES APPENDIX A: SPECIFICATIONS DIMENSIONS 17.3” (W) X 6.4” (D) X 1.75” (H) 439MM (W) X 163MM (D) X 44MM (H) 1U FORM FACTO

Copyright © 2002 Raritan Computer, Inc. SCS232-0C July 2002 Raritan Computer Inc. 400 Cottontail Lane Somerset, NJ 08

22 CONSOLESWITCH SCS232 USER’S MANUAL APPENDIX B: PIN-OUT DIAGRAMS In order to provide maximum port density and to enable simple UTP (Category 5) ca

APPENDICES 23 SCSDB9F NULLING SERIAL ADAPTER PIN-OUT RJ45 (Female) DB9 (Female) 1 8 2 1, 6 3 2 4 SHELL 5 5 6 3 7 4 8 7 SCSDB9M NULLING SERIAL ADA

24 CONSOLESWITCH SCS232 USER’S MANUAL APPENDIX C: UPDATING PARAGON FIRMWARE NOTE: This Appendix does not apply to users deploying ConsoleSwitch as a

APPENDICES 25 PARAGON FIRMWARE UPDATE INSTRUCTIONS 1. Download the Paragon Firmware distribution file (ParagonFirmware.zip), available at the Rarit

26 CONSOLESWITCH SCS232 USER’S MANUAL 5. Click the “Test Hex File” button to ensure file integrity. 6. Click “Check Device Information” to confirm s

APPENDICES 27 APPENDIX D: UPDATING CONSOLESWITCH SCS232 FIRMWARE INTRODUCTION To take advantage of the latest features and ensure the best perform

28 CONSOLESWITCH SCS232 USER’S MANUAL 10. ConsoleSwitch SCS232 will clear the screen and display the following: Transmit the update file using the

APPENDIX E: PARAGON WITH CONSOLESWITCH FAQ 29 APPENDIX E: PARAGON WITH CONSOLESWITCH FAQ This section addresses questions specific to operational i

30 CONSOLESWITCH SCS232 USER’S MANUAL APPENDIX F: CONSOLESWITCH FAQ Q: My device has a serial console port jack that is RJ45. Can I use a normal Ca

255-60-0010

This page intentionally left blank

FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rule

This page intentionally left blank

TABLE OF CONTENTS CHAPTER 1: MANUAL NOTES ...1 VERSION APPLICAB

CHAPTER 1: MANUAL NOTES 1 CHAPTER 1: MANUAL NOTES VERSION APPLICABILITY Contents in this manual are applicable to ConsoleSwitch™ SCS232 firmware ver
